Large wired site layouts
Camera kit
From $1,569
Starting configuration32 cameras
QuarkView · XM-7932K-2xPOE216-32x605GP-AI-50
01 / 03
32-camera system reference; recording drive selected separately
| Camera resolution | 5MP / 2592 × 1944 |
|---|---|
| Recorder channels | 32 |
| Supplied cameras | 32 |
| Audio | Two-way microphone and speaker |
| PoE arrangement | 2 × 16-port external PoE switches |
| Camera lens | 3.6mm |
| Compression | H.265 / H.265X |
Listed packages are price references. Other camera quantities and storage requirements can be discussed in your quote.
| Model | XM-7932K-2xPOE216-32x605GP-AI-50 |
|---|---|
| Recorder drive interfaces | 2 SATA ports |
The system combines thirty-two 5MP outdoor cameras and two 16-port PoE switches. This is an IP NVR layout using separate switches for camera power. Keep switch uplinks and the recorder on the recording network.
Give each view a location-based name and use the camera groups to plan bitrate and retention. Microphone and speaker audio support conversation at the camera. Name channels by entrance, aisle or building so the recording layout follows the site plan.
Group camera cables by site area and route switch uplinks to the recorder network. Name each view, initialise the selected recording drive and set the recording schedule. The QuarkView installation and storage guides below help plan the powered connections and recording load.
A reference for the listed model family. Match the device label and on-screen interface before following setup steps.
The system uses two external 16-port PoE switches with the IP NVR.
It specifies drive capacity. Recording days depend on the combined camera bitrates and recording schedule.
The switches power groups of cameras and carry their video to the recorder network. Recording channels remain a separate NVR capacity.
Start with XM-7932K-2xPOE216-32x605GP-AI-50 and the configuration you need. Include quantity per model, delivery destination, target timing and any sample or documentation requirements.
Sample terms, minimum order quantity, customization scope, compatibility and lead time need confirmation for this model and configuration. Use the purchase options above for an available individual purchase.
Choose a listed package or ask about a project configuration.
Request a QuoteRelated products
