QuarkView 6108K 8CH PoE Network Video Recorder

Small wired camera installations

Recorder

Recorder channels: 8

HDMI/VGA display output
H.265 compression
ONVIF camera access

$199

QuarkView · XM-6108K

01 / 01

Model reference image with QuarkView branding

Specifications

Channels	8 channels
Display output	HDMI and VGA
Compression	H.265
Listed bandwidth	80M
Camera resolution support	1080P, 3MP, 4MP, 5MP and 8MP
Camera protocol	ONVIF
Recording modes	Manual, alarm, motion and scheduled

Full specifications and package contents

Listed packages are price references. Other camera quantities and storage requirements can be discussed in your quote.

Model	XM-6108K
Listed storage configurations	HDD; No HDD configuration
Listed maximum HDD	Up to 14TB; match the drive and firmware revision

What is included

One 6108K 8CH PoE NVR
USB mouse, user manual and listed 52V 2.5A NVR power adapter
Recording HDD purchased separately

Product details

Build an eight-channel recording plan

The current model is the 6108K 8CH recorder. Camera channels, physical powered ports and the PoE power budget are separate limits. Match the camera load and recording settings to the supplied hardware.

More product details

Install the recording drive

The No HDD option supplies no recording drive. Install a suitable surveillance HDD, initialise it in the recorder, then check live views, scheduled recording and playback. The listed 14TB maximum is a model reference; it does not determine retention days.

Connect and review

Use HDMI or VGA for a local display. ONVIF provides a path for compatible third-party cameras, while event metadata, audio and advanced controls depend on the camera, firmware and recorder combination. Use the storage and compatibility guides below to plan the installation.

Setup resources and product questions

Product setup guides

QuarkView setup support (opens a new tab)
Use the instructions supplied with the 6108K hardware. The historical 6016K manual is not assigned to this model.

Related guides

Discuss samples, bulk supply or OEM requirements

Start with XM-6108K and the configuration you need. Include quantity per model, delivery destination, target timing and any sample or documentation requirements.

Sample terms, minimum order quantity, customization scope, compatibility and lead time need confirmation for this model and configuration. Use the purchase options above for an available individual purchase.

Choose a listed package or ask about a project configuration.
